XCMG QY25K
XCMG QY25K
Condition
Used
1
of
6
XCMG QY25K
1
of
6
Overview
Description
XCMG Official Secondhand Mobile Crane QY25K Excellent working condition Price
Certification: CE/ISO9001
Model Number: QY25K
Brand Name: XCMG
Place of Origin: China
Span: 6.5 m
Max. Lifting Height: -
Max. Lifting Load: 25 Ton
Rated Lifting Moment: -
Rated Loading Capacity: 25 Ton
Application: Construction
weight: 33000.000kg
Moving Type: Other
Year: 2007
Boom length: 34.5 m
Rated power: 192 KW
: 7 days for ready goods
: 1 Piece
: Any Port In China
DimensionUnitQY25K
Overall lengthmm12300
Overall widthmm2500
Overall heightmm3350
Weight
Total weight in travelkg31750
Front axle loadkg6550
Rear axle loadkg25200
Power
Engine model SC8DK280Q3
Engine rated powerkW/(r/min)206/2200
Engine rated torqueN.m/(r/min)1112/1400
Travel
Max. travel speedkm/h80
Min. turning diameterm22
Min. ground clearancemm260
Approach angle°16
Departure angle°13
Max. grade ability%40
Fuel consumption for 100kmL≈37
Main performance
Max. rated total lifting capacityt25
Min. rated working radiusmm3000
Turning radius at turntable tailm3.065
Max. lifting torquekN.m961
Base boomm10.4
Fully extended boomm39.5
Fully extended boom+jibm47.8
Longitudinal outrigger spanm5.14
Lateral outrigger spanm6
Working speed
Boom luffing times68
Boom full extension times150
Max. swing speedr/min2.5
Max. speed of main winch (single rope) (no load)m/min125
Max. speed of aux. winch (single rope) (no load)m/min125
XCMG Official Secondhand Mobile Crane QY25K Excellent working condition PriceCertification: CE/ISO9001
Model Number: QY25K
Brand Name: XCMG
Place of Origin: China
Span: 6.5 m
Max. Lifting Height: -
Max. Lifting Load: 25 Ton
Rated Lifting Moment: -
Rated Loading Capacity: 25 Ton
Application: Construction
weight: 33000.000kg
Moving Type: Other
Year: 2007
Boom length: 34.5 m
Rated power: 192 KW
: 7 days for ready goods
: 1 Piece
: Any Port In China
DimensionUnitQY25K
Overall lengthmm12300
Overall widthmm2500
Overall heightmm3350
Weight
Total weight in travelkg31750
Front axle loadkg6550
Rear axle loadkg25200
Power
Engine model SC8DK280Q3
Engine rated powerkW/(r/min)206/2200
Engine rated torqueN.m/(r/min)1112/1400
Travel
Max. travel speedkm/h80
Min. turning diameterm22
Min. ground clearancemm260
Approach angle°16
Departure angle°13
Max. grade ability%40
Fuel consumption for 100kmL≈37
Main performance
Max. rated total lifting capacityt25
Min. rated working radiusmm3000
Turning radius at turntable tailm3.065
Max. lifting torquekN.m961
Base boomm10.4
Fully extended boomm39.5
Fully extended boom+jibm47.8
Longitudinal outrigger spanm5.14
Lateral outrigger spanm6
Working speed
Boom luffing times68
Boom full extension times150
Max. swing speedr/min2.5
Max. speed of main winch (single rope) (no load)m/min125
Max. speed of aux. winch (single rope) (no load)m/min125
Certification: CE/ISO9001
Model Number: QY25K
Brand Name: XCMG
Place of Origin: China
Span: 6.5 m
Max. Lifting Height: -
Max. Lifting Load: 25 Ton
Rated Lifting Moment: -
Rated Loading Capacity: 25 Ton
Application: Construction
weight: 33000.000kg
Moving Type: Other
Year: 2007
Boom length: 34.5 m
Rated power: 192 KW
: 7 days for ready goods
: 1 Piece
: Any Port In China
DimensionUnitQY25K
Overall lengthmm12300
Overall widthmm2500
Overall heightmm3350
Weight
Total weight in travelkg31750
Front axle loadkg6550
Rear axle loadkg25200
Power
Engine model SC8DK280Q3
Engine rated powerkW/(r/min)206/2200
Engine rated torqueN.m/(r/min)1112/1400
Travel
Max. travel speedkm/h80
Min. turning diameterm22
Min. ground clearancemm260
Approach angle°16
Departure angle°13
Max. grade ability%40
Fuel consumption for 100kmL≈37
Main performance
Max. rated total lifting capacityt25
Min. rated working radiusmm3000
Turning radius at turntable tailm3.065
Max. lifting torquekN.m961
Base boomm10.4
Fully extended boomm39.5
Fully extended boom+jibm47.8
Longitudinal outrigger spanm5.14
Lateral outrigger spanm6
Working speed
Boom luffing times68
Boom full extension times150
Max. swing speedr/min2.5
Max. speed of main winch (single rope) (no load)m/min125
Max. speed of aux. winch (single rope) (no load)m/min125
