2000 Paal, Germany KONTI 325 D
Overview
Report Ad
Safety Tips
Description
Technical specifications Manufacturer Paal, Germany Type KONTI 325 D Year of construction 2000 Press power 95 t Drive power 2 x 45 kW Feed channel 1750 x 1020 mm Press channel dimensions 750 x 1100 mm (h x w) Bale weight 500-750 kg, depending on material Average throughput rates: Density of 35 kg/cbm 14t/h Density of 60 kg/cbm 27 t/h Density of 100 kg/cbm 38 t/h Tying system 4-fold vertical, fully automated Transport dimension 12.352 x 2340 x 2800 mm (LxWxH) Weight Approx 26 t Following steps of overhauling have been passed: Press derusted and lacquered new. Hydraulic oil tank drained and cleaned completely. Heating rods for preheating of hydraulic oil verified and cleaned. Tying system unit overhauled, needle check rail nuts and nuts of wire drawing replaced, bearings renewed and unwinding unit overhauled. The press bottom being in a good condition had been overhauled already. The lateral press channel is in a good condition as well. Knives and counter knives have been renewed. Upper guide rolls of press heading tool renewed. Bottom rolls renewed
